Kingst LA1010 User Manual

Kingst Virtual Instruments User Guide www.qdkingst.com
2016-8-20
6
LA1000 Series：
Product type
LA1002
LA1010
Input
Number of channels
8
16
Max sampling rate
24M@8CH
100M@3CH, 50M@6CH
32M@9CH, 16M@16CH
Measurement bandwidth
5MHz
20MHz
Min detectable pulse width
80ns
20ns
Max sampling depth
10G/channel
10G/channel
Input voltage range
0V~+5V
-50V~+50V
Input impedance
220KΩ，12pF
220KΩ，12pF
Threshold voltage
≤1.0V Low level
≥2.0V High level
Adjustable: -4~+4V
Min step: 0.01V
PWM
Output
Number of channels
--
2
Output frequency range
--
0.1～10MHz
Min step of period
--
10ns
Min step of pulse width
--
10ns
Output voltage
--
+3.3V
Output impedance
--
50Ω
Power
supply
Power supply port
USB2.0/3.0
USB2.0/3.0
Standby current
50mA
100mA
Max operating current
80mA
150mA
PC
software
Supported protocols
UART/RS-232/485, I2C, SPI, CAN, DMX512, HDMI CEC,
I2S/PCM, JTAG, LIN, Manchester, Midi, Modbus, 1-Wire, UNI/O,
SDIO, SMBus, SWD, USB1.1, PS/2, NEC Infrared, Parallel, etc.
Supported OS
Windows XP, Vista, Windows 7/8/10(32bit/64bit)
