K- SENSORS User Manual
K-Force Plates
User qualification
The K-Force Plates must be used by a
health professional.
Description
K-Force Plates are two independent force
platforms for rehabilitating balance and
assessing lower limb muscular symmetry
and strength.
Benefits
K Plates are equipped with electronic force
transducers and give real-time acoustic and
optic biofeedback on your Smartphone or Tablet through the Kinvent Physio app. Each
platform has 4 independent sensors on the corners, allowing measurement of the center
of pressure. Each foot comes with a mounting thread so that the sensor can be
fixed on a
surface.
Technical Features
Minimum Requirements
Android 5.0+ or iOS 10.0+, Bluetooth
Low Energy
Weight
2000 grams / 4.4 lbs
Dimensions (H x W x D)
Metric 30 x 346 x 191mm
US : 1.18x13.62x7.52”
Wireless Range
Up to 40 meters / 44 yd
Max Force
600 kg / 1322 lbs per platform
Battery
20 hours continuous use, 2h for
charging
Power supply
Li-Po Battery 800 mAh
Radiated output Power
Max. 10 mW
Wireless transmission
Frequency
2.4GHz band (Bluetooth Low Energy
5.1)
Accuracy
< 0.1%, +-0.1kg / +-0.22lbs
Eco features
Self-activated “sleep” mode after 10
minutes.
Units
Selectable in application KgF, N, lbs
Acquisition frequency
1000Hz Full CoP
