K- SENSORS User Manual
K-Pull
User qualification
The K-Pull must be used by a health professional.
Description
Traction dynamometer for the measurement of
isometric strength and biofeedback training.
K-Pull enables independent measurements. It can be
fixed on a physiotherapists table, on the espalier or on
pulley machines.
Accessories :
K-Pull is provided with accessories for a turnkey operation:
- 2 carabiners (rated for max 600 kg / 1322 lbs)
- 2 loop fastening accessories allowing attachment to
a physiotherapy table or to a wall bar and to the
desired limb with maximum force of 180 kg /396 lbs
- 2 different resistance elastics for exercise with
resistance.
- Yellow Resistance Band 0.5-4 kg / 1.1 to 8.8lbs
of resistance (lightest) used for Shoulders and
shins
- Red Resistance Band - 1-8 kg / 2.2 to 17.6 lbs of resistance (light) used for
Biceps and triceps
- 1 adjustable rigid strap for the measurement of the maximum isometric force rated
for max 600 daN / 611 kg / 1347 lbs .
Technical Features
Minimum requirements
Android 5.0+ or iOS 10.0+, Bluetooth Low Energy
Weight
150 g / 5.29 oz
Dimensions (H x W x D)
Metric: 115 x 63 x 33 mm ; US : 4.53 x 2.48 x 1.3 “
Wireless Range
Up to 40 meters / 44 yd
Max Force
300 Kg / 661 lbs
Battery
12h of autonomy, 2h charging
Power supply
Li-Po battery 280 mAh
Wireless transmission
frequency
2.4GHz band (Bluetooth Low Energy 5.1)
Accuracy
< 0.1% , C3 Class
Acquisition frequency
1000Hz
