Specification
Number of Rows 6 Row 30" 8 Row 30"
Weight Empty (Mechanical)* 5163 lb (2341.8 kg) - 5443 lb (2468.9 kg) 5886 lb (2669.8 kg) - 6269 lb (2843.6 kg)
Weight Empty (Vacuum)* 5163 lb (2341.8 kg) - 5443 lb (2468.9 kg) 5886 lb (2669.8 kg) - 6269 lb (2843.6 kg)
*Seed meter/vacuum system - 13 gpm @ 2000 psi (49 LPM @13790 kPa) case drain plus one SCV
(pressure and return) for vacuum fan hydraulic motor.
Axle Weight (Empty)** 4245 lb (1925.4 kg) 8420 lb (3819.2 kg)
Tongue Weight (Empty)** 918 lb (416.3 kg) 1820 lb (825.5 kg)
**Weight based off a typical configuration of a complete machine.
Transport Height 10' 6" (3.2M) 10' 6" (3.2M)
Planting Length 19' 8" (6.0M) 19' 8" (6.0M)
Transport Length 23' 9" (7.3M) 26' 5" (8.4M)
Planting Width 16' 10" (5.2M) 21' 10" (6.7M)
Transport Width 11' 2" (3.5M) 11' 2" (3.5M)
Seed Capacity 1.75 bu. (Vacuum / Hopper); 1.90 bu. (Mechanical / Hopper)
Transport Tires
Four 7.50" x 20" 8 ply rib implement tires w/ center groove - Inflate to 40 psi (275.7 kPa)
Contact Drive Tires
Two 4.10" x 6" spring-loaded contact drive tires.
- Inflate to 50 psi (344.7 kPa)
Field Lift
One center post lift cylinder. (Front or rear mount.)
Row Markers
Two-fold low profile with 16" concave, solid blades and cast iron hubs.
*Base machine weights include planter frame including row markers, hydraulic cylinders, hoses, fittings, tires, wheels,
drive and drill shafts, sprockets, chains and required drive components, parking jack, safety/warning lights, SMV sign,
transport safety chain, and Kinze pull row units (closing wheel arms less closing wheels) with seed hopper, lid, and dual
quick adjustable down force springs option. Vacuum includes additional weight of fan, manifolds, and hoses.
Tractor Hydraulic Requirements
Configuration Requirements Description
Base machine with mechanical meters.
2 SCV
10 gpm
(38 L/min)
#1 SCV: Planter lift
#2 SCV: Markers/fold (manual selector valve)
Base machine with vacuum meters.*
3 SCV
25 gpm
(95 L/min)
#1 SCV: Planter lift
#2 SCV: Markers/fold (manual selector valve)
#3 SCV: Vacuum fan
Base machine with vacuum meters and
tractor mounted PTO pump.*
2 SCV
15 gpm
(57 L/min)
#1 SCV: Planter lift
#2 SCV: Markers/fold (manual selector valve)
Specifications
TOOLS REQUIRED
Hardware Size / Tool Required
/" = /" /" = /"
(nut for /" hardware uses /" tool)
/" = 1/" 1/" = 1/"
/" = /" /" = /" /" = 1/" 1/" = 2/"
/" = /" /" = /" 1" = 1/"
