Kinze 3500 - Cylinder Information

TM
Model 3500M0258-01
Rev. 10/14 2-11
Machine Operation
CYLINDER INFORMATION
Row Marker
Cylinder
Transport Latch
Cylinder
Lift Cylinder Rotation Cylinder
Intended Use
Double Acting
Applications
Double acting
applications
Double Acting
Applications
Double Acting
Applications
Piston
Ductile Iron Ductile iron Ductile Iron Ductile Iron
Gland
Ductile Iron Ductile iron Ductile Iron Ductile Iron
Tube
ST 52 DOM Tubing Cast ST 52 DOM Tubing ST 52 DOM Tubing
Rod
1045 Nitro Rod 1045 Nitro rod 1045 Nitro Rod 1045 Nitro Rod
End Mounts
U-Brackets None Trunnion Tang
Tube Seal
Buna O-Ring with
Polytemp Back-up
O-Ring with
polytemp back-up
Buna O-Ring with
Polytemp Back-up
Buna O-Ring with
Polytemp Back-up
Rod Seal
Polyester Alloy
U-cup
Polyester alloy u-cup
Polyester Alloy
U-cup
Polyester Alloy
U-cup
Rod Wiper
Polyester Alloy
Snap In
Polyester alloy snap
in
Polyester Alloy
Snap In
Polyester Alloy
Snap In
Piston Seal
T-Seal HNBR T-Seal HNBR PTFE Seal T-Seal HNBR
Specifications
Product
Category
Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder
Maximum
Stroke
8" (20.32 cm) 2.5" (6.35 cm) 48" (121.9 cm) 16" (40.6 cm)
Working
Pressure
2350-3000 PSI
(16202.68-20684.27
KPa)
3000 PSI
(20684.27 kPa)
3000 psi
(20684.27 kPa)
3000 psi
(20684.27 kPa)
Bore Size
2" (5.08 cm) 1.5" (3.81 cm) 3" (7.6 cm) 3" (7.6 cm)
Shaft
Diameter
1" (2.54 cm) .750" (1.905 cm) 1.5" (3.81 cm) 1.25" (3.1 cm)
Cylinder
Configuration
Simple Simple Simple Simple
Cylinder
Action
Double Double Double Double
Material
Steel, Ductile Iron
Steel, Ductile Iron,
Cast
Steel, Ductile Iron Steel, Ductile Iron
Mounting
Method
U-Bracket None Trunnion Tang
Mount
Location
End Cap End Cap Barrel End Cap
Cylinder
Style
Welded Machined Welded Welded
