M0258-01Model 3500
6-24 9/14
TM
Lubrication and Maintenance
Lubricate bushings in mounting bracket and links at frequency indicated in Lubrication of this section. Check each bolt
for proper torque. If bolt is loose, it should be removed and bushing inspected for cracks and wear. Replace bushing if
necessary.
NOTE: Use only hardened flat washers. Replace damaged flat washers with proper part. Torque bolts to 130 ft.
lbs (176.3 N-m).
Wheel hub is equipped with sealed bearings. If a bearing
sounds or feels rough when wheel is rotated, replace them.
ROW UNIT MOUNTED BED LEVELER
ROW UNIT MOUNTED RESIDUE WHEEL
