Kinze 3500 - Page 27

TM
Model 3500M0258-01
Rev. 10/14 2-13
Machine Operation
Hydraulic Hose Information (Continued)
Part Number A1041 A1021 A1055 A1018 A1076
Description
Hose Assembly,
³⁄" x 130"
Hose Assembly,
³⁄" x 56"
Hose Assembly,
³⁄" x 66"
Hose Assembly,
³⁄" x 40"
Hose Assembly,
³⁄" x 30"
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form Hose:Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D. ³⁄" (9.525 mm) ³⁄" (9.525 mm) ³⁄" (9.525 mm) ³⁄" (9.525 mm) ³⁄" (9.525 mm)
O.D.
.63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm)
Minimum Bend
Radius
2"
(5.08 cm)
2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm)
Working Pres-
sure
3250 psi
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
Temperature
Range
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
Media Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
