TM
Grain Cart
M0276-01
Rev. 2/18 3-7
Lubrication and Maintenance
Every 500 Hours or Yearly
REPACK CARRIER ROLLER WHEEL BEARINGS
Every 2000 Hours or Every 5 Years
Off Season Storage
For optimum life, tracks should be stored indoors, in dry environment with a temperature between 40° - 77° (5° - 25° C).
The tracks should not be exposed to direct sunlight or heat. No petrochemicals and related vapors, no electrical devices
producing ozone should be placed in the same area.
Should it be necessary to disassemble the tracks from the undercarriage, lay them on the ground on one edge avoiding
bending radius less than 30" (750 mm). Do not lay the rubber components on dirty surfaces contaminated by oil, grease
or other chemical products
Do not paint rubber components.
DRAIN AND REPLACE IDLER AND MIDROLLER RESERVOIRS
Use 10W30 Universal Transmission/Hydraulic Oil
Wheel Bolt Torque Chart
Size
Torque (N-m) Torque (ft-lb)
N-06 7.4 +⁄− 1.5 10 +⁄− 2
