M0276-01Grain Cart
3-26 Rev. 2/18
TM
Lubrication and Maintenance
HYDRAULIC CONTROL SCHEMATIC - MANUAL
White
Yellow Red
Interlock
Valve
Counter balance valve
Auger
Fold
Tilt
Spout
Flow Gate
