Kinze 851 - Moisture Sensor Harness Routing

TM
Grain Cart
M0276-01
Rev. 2/18 3-29
Lubrication and Maintenance
MOISTURE SENSOR HARNESS ROUTING
DETAIL A
DETAIL B
Harness To Enter Tub Here
Use Supplied Grommet
To Tractor
Cable Routed Into R.H. Side Of Frame
Cable Exit Frame
(48.5)
SECTION C-C
Connection Between
Supplied Harnesses
Approximate Location
Connection Between
Supplied Harnesses
Approximate Location
DETAIL D
C
B
A
D
C
