CHAPTER 1 CK20(H)
1-28
S196-WOO Jul. 2003
CK20
CK20H
196W141A
6. After the new filter has been replaced, fill with oil up
to the upper line of the gauge.
7. After running the engine for a few minutes, stop it
and check the oil level again, add oil to the pre-
scribed level.
8. Make sure that the transmission fluid doesn’t leak
through the seal.
(1) Hydraulic Oil Filter
(2) Transmission Oil Filter (CK20H)
3. Remove the oil filter.
4. Put a film of clean transmission oil on the rubber
seal of the new filter.
5. Tighten the filter quickly until it contacts the mount-
ing surface.
Tighten the filter by hand an additional half turn only.
(1) Oil Inlet
(2) Gauge
(A) Oil Level is Acceptable Within this Range
196W140A
196W138A
• To prevent serious damage to the hydraulic
system, use only a KIOTI genuine filter.
IMPORTANT
