INSTRUMENT PANEL AND CONTROLS 4-13
069O424A 069O425A 069O426A
Move the front wheel drive lever rear-
ward (A) to engage the front wheel drive
mechanism.
During ordinary farming work, keep the
lever forward (B) to leave the mecha-
nism disengaged. The front wheel drive
mechanism is very effective on the fol-
lowing jobs.
1. On slopes and in wet fields, or when
connected to the Trailer or the Front-
End-Loader where great traction is
required.
2. On sandy land.
3. To prevent the tractor being thrust for-
ward during rotary tilling hard soil.
4. Entering a job location or going over a
high bank.
FRONT WHEEL DRIVE LEVER
(1) Front Wheel Drive Lever
(A) Engagement (B) Disengagement
PTO CHANGE LEVERPTO SAFETY SWITCH(ON/OFF)
Push the PTO switch(On, Off) when stop
the PTO in case of emergency.
(1) PTO Switch
(A)
- ON (B) - OFF
(A) 540rpm (B) 1000rpm
Two PTO speeds can be obtained by
shifting the PTO speed lever from the
operator’s seat.
CAUTION
To avoid personal injury:
Disengage PTO, stop engine, and
allow all rotating components to
come to a complete stop before
connecting, disconnecting, ad-
justing, or cleaning any PTO dri-
ven equipment.
To Next Page
