PERIODIC SERVICE 10-5
069OA05A 069OA06A
CHECKING COOLANT LEVEL
(1) Reserve Tank
(A) Full (B) Low
CAUTION
To avoid personal injury:
Do not remove radiator cap while
coolant is hot. When cool, slowly
rotate cap to the first stop and
allow sufficient time for excess
pressure to escape before re-
moving the cap completely.
1. Check to see that the coolant level is
between the “FULL” and “LOW” marks
of recovery tank.
2. When the coolant level drops due to
evaporation, add water only up to the
full level.
In case of leakage, add anti-freeze and
water in the specified mixing ratio up
to the full level.
(See “Flush Cooling System and
Changing Coolant” in every 2 years
maintenance.)
IMPORTANT
If the radiator cap has to be
removed, follow the caution
above and securely retighten the
cap.
Use clean, fresh water and anti-
freeze to fill the recovery tank.
If water should leak, consult your
local KIOTI Dealer.
(1) Radiator Net (A) Detach
CLEANING GRILL, RADIATOR NET
To Next Page
