55
Left housing case
微动开关挡板
微动开关
油开关
燃油泵
左机壳
油开关手柄
负压管
油开关
燃油泵
左机壳
油箱
油管I
卡箍
油管
Left housing case
Fuel switch lever
Fuel pump
Fuel switch
Micro switch
baffle
Fuel pump
Fuel hose
Diaphragm tube
Fuel hose
fuel switch
Clamp
Left housing case
Fuel tank
Fuel hose
© 2011 Kipor Power Systems, Inc.

Table of Contents

Other manuals for Kipor IG2000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kipor IG2000 and is the answer not in the manual?

Kipor IG2000 Specifications

General IconGeneral
Rated Power1.6 kW
Voltage230 V
Frequency50 Hz
Fuel TypeGasoline
Starting SystemRecoil
Weight22 kg
Engine Type4-stroke, OHV
Noise Level54-59 dB(A)
Continuous Operation Time4 h (at rated load)
