With the end cover (64)
on
the machine, test the speeds
again
to
be sure no change
took
place in the control plate.
With mixer working perfectly, place bowl (38) on the bowl
screw cap (40). Place flat beater (32) on
the
agitator shaft
(35). Lower the head
so
beater
is
at
bottom
of
bowl. There
should be approximately 1 /16" clearance between bowl and
beater. If beater
is
too
close to bowl,
turn
in the adjusting
screw (50) and
out
if
it
is
too
far away.
Mi
xer
is
now ready
for operation.
SECTION 7
REPAIRS TO MODEL KS-A
BOWL
LIFT ASSEMBLY
18
FIG. 4
A. The Models K45 and KS-A KitchenAid mixers have
different types
of
bowls and are different in size. The K45
bowl
is
held stationary
by
mechanical means at
bottom
of
the pedestal, whereas
the
KS-A bowl slides up and down
on
gibs
on
the front
of
the pedestal. On the Model KS-A, the
gear case and
motor
housing is stationary making it necessary
to
move
the
bowl.
B.
Should the mixer be tipped over
or
knocked
off
the table
or
counter and the bowl support assembly (14, Fig. 4) will be
broken. To repair,
it
is necessary
to
replace the bowl support.
C.
To replace the bowl support (14 ), remove the four
5
I 16" -18 x 3 I
4"
round
head screws (12) and lift the gear case
and
motor
housing
off
the column (13).
