4-9
TC Drawer Cover Screws
5. Disconnect the wire connector on the
temp-controlled drawer cover from the
wiring harness.
6.
Remove the two screws from the temp-
controlled drawer cover and remove the
cover.
Left Cover Connector
(8-Pin)
Right Cover Connector
(6-Pin)
