8-2
ADJUSTING THE FREEZER DOOR
4 Alignment Holes
(Right Side)
2. Pull the freezer drawer out.
3. Remove the food from the drawer.
4. Lift the liner out of the freezer drawer.
5. Remove the bottom T-15 screw from both
sides of the the freezer drawer front.
6. Close the freezer drawer and adjust the
door front so that it is properly aligned and
the gasket seats evenly against the cabinet.
NOTE: The cabinet trims may need to be
removed to view the door seal.
7. Without moving the freezer drawer front,
slowly open the freezer drawer, and locate
one of the holes in the left and right four
hole groupings that are properly aligned.
8. Install the two screws you removed in step
5, in the left and right aligned holes, and
tighten them securely.
9. Close the freezer drawer, and make sure
that the gasket seats securely against the
cabinet.
Keep Edges
Parallel
A
lignment
Holes
F
reezer
Door
+
+
Bottom Screw
Freezer Door
Gasket
1. Unplug refrigerator or disconnect power.
NOTE: This adjustment allows you to level
the freezer door with the cabinet surface to
prevent leakage and frost from occurring.
