KitchenAid KBFC42FS - Component Access and Locations; Unit Compartment Component Locations

4-1
This section instructs you on how to service components inside the Built-In French Door Bottom-
Mount Refrigerator. The components and their locations are shown below.
COMPONENT ACCESS
Condenser Fan Motor
Main Control Board
Compressor
24V
Transformer
COMPONENT LOCATIONS
Unit Compartment Components
Inverter
Power Switch
Low Voltage Control Board
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
WARNING
