KitchenAid KBFC42FS - Removing Flipper Mullion Actuator;Contact

4-11
4. To remove the top or bottom heated
flipper mullion actuator/electrical con-
tact:
a) Open the refrigerator doors.
d)
Remove the two hex-head screws from
the actuator/electrical contact.
b) Use a flat-blade screwdriver, and un-
screw the cap from the actuator/elec-
trical housing.
c)
Pry off the cover from the actuator/
electrical contact.
Top Mullion
Actuator/
Electrical Contact
Bottom Mullion
Actuator/
Electrical Contact
e) Disconnect the spade connector from
the actuator/electrical contact terminal.
Screw Cap
Bottom Mullion
Actuator / Electrical Housing
Actuator / Electrical Contact Screws
Actuator / Electrical Contact Terminal
Actuator / Electrical
Contact Cover
