4-23
5. To remove the fill tube heater:
a) Remove the ice maker (see step 4).
b) Unlatch and disconnect the heater
connector from the main harness.
c)
Remove the two hex-head screws
from the heater and slide the heater
off the fill tube.
d) Disconnect the two wire connectors
from the heater terminals.
Fill Tube Heater Screws
Heater Connector
Heater Connectors
To Next Page
