2-10
2. Remove the control knob.
3. Remove the black rubber grommet.
4. Using needle-nose pliers, remove the gray
shield inside the burner valve opening.
A. Control knob
B. Black rubber grommet
C. Gray shield
M
e
d
A
B
C
5. Tightenscrew“A”toreduceameheight.
Loosenscrewtoincreaseameheight.
A. Adjustment screw - inner crown
B. Adjustment screw - outer crown
B
A
6. Replace the control knob.
7. SettheoutercrownametoLO.
8. Remove the control knob.
9. Tightenscrew“B”toreduceameheight.
Loosenscrewtoincreaseameheight.
10. Replace the gray shield. Use a screwdriver
to help push the shield into place.
11. Replace the black rubber grommet.
12. Replace the control knob.
13.Testtheamebyturningthecontrolfrom
LOtoHI,checkingtheameateach
setting.
If you need Assistance or Service:
Please reference the “Assistance or Service”
section of the Use and Care Guide or contact
the dealer from whom you purchased your
cooktop.
