2-21
5. For LP gas conversion:
Completely tighten screw “A” to set the
minimumameheight.
For Natural gas conversion:
 Tightenscrew“A”toreduceameheight.
Loosenscrewtoincreaseameheight.See
“Complete Burner Adjustment” section.
A. Inner crown adjustment screw
B. Outer crown adjustment screw
B
A
6. Replace the control knob.
To Adjust Outer Crown Flame:
1. SettheoutercrownametoLO.
2. Remove the control knob.
3. For LP gas conversion:
Completely tighten screw “B” to set the
minimumameheight.
For Natural gas conversion:
 Tightenscrew“B”toreduceameheight.
Loosenscrewtoincreaseameheight.See
“Complete Burner Adjustment” section.
4. Replace the gray shield. Use a screwdriver
to help push the shield into place.
5. Replace the black rubber grommet.
6. Replace the control knob.
7. Testtheamebyturningthecontrolfrom
LOtoHI,checkingtheameateach
setting.
Complete Burner Adjustment
1. Checkburnerame(s)forpropersizeand
shape. The cooktop “low” burner ame
should be a steady blue ame approxi-
mately 1/4" (0.64 cm) high.
A. Low ame
B. High ame
A
B
2. Completelyllouttheconversionlabeland
attach label to bottom of the cooktop next
to the rating tag. Do not cover the rating
tag with the conversion label.
3. Savetheoricesremovedfromthecook-
top along with these instructions for future
reference.
Read “Sealed Surface Burners” section in
the Use and Care Guide supplied with your
cooktop.
