5. WHAT HAPPENS IF...
...the stove does not ignite
In case of no ignition, the “NO FIRE” alarm is displayed.
Hold button 4 (switch on/off) for a few seconds to restore the stove to standard conditions (remove the alarm).
...lack of power for a few seconds
Once the power is restored, the stove immediately restarts from the status it had before the power outage
(recovering the set work power).
... lack of power
As soon as the power is restored after a power outage, the stove sets on “STOP FIRE” mode and carries out
the entire switch off cycle until its cooling. Once this phase is completed, the stove can be normally switched
on to proceed working at the set power.
…the fire door is open or closed improperly
In case the door is open or closed improperly, the motor reducer cannot be powered electrically, not allowing
the stove to switch on. If the fire door is opened during the normal operation, the stove burns all the pellet in
the brazier, activating the “ALAR NO FIRE” alarm (sudden switch off). The flue is dirty, blocked or not
manufactured correctly.
In case the flue is dirty, blocked or not manufactured correctly, the motor reducer cannot be powered
electrically not allowing the stove to switch on. If the flue blocks during the normal operation, the stove burns
all the pellet in the brazier, activating the “ALAR NO FIRE” alarm (sudden switch off).
...the stove is overheated
In case of water over-temperature in the boiler, the message
“ALAR HOT H2O” is displayed first, followed by an acoustic alarm. At this point the motor reducer is not
electrically powered, because the rearm safety thermostat is activated. Therefore the thermostat must be
rearmed before switching on the stove.
...pellet insert unhooked or hooked improperly
In case the pellet insert is unhooked or hooked improperly, the motor reducer cannot be powered electrically,
not allowing the insert to switch on. If it is unhooked during the normal operation, the insert burns all the pellet
in the brazier, activating the “ALAR NO FIRE” alarm (sudden switch off).
6. ALARMS
The board intervenes and signals the occurred irregularity in case of functioning anomaly, operating in
different mode depending on type of alarm. The following alarms are foreseen in the board.
DISPLAY
ORIGIN OF ALARM
ALAR SOND H2O
Faulty or disconnected water temperature probe
ALAR HOT H2O
Water over-temperature. When water temperature exceeds 92°C
ALAR SOND FUMI
Faulty or disconnected flue gas temperature probe.
ALAR HOT TEMP
Flue gas over-temperature. When flue gas temperature exceeds 280°C
ALAR NO FIRE
No ignition. When flue gas minimum temperature (Pr13) is not reached within
maximum ignition cycle time (Pr01).
ALAR NO FIRE
Sudden switch-off during work phase. When, during work, the flue gas
temperature drops below minimum threshold (Pr13).
NO H2O
No water level. When water in boiler does not reach minimum level (only on
Sicuro Top BI-FIRE and BI-FIRE MID system)
Every alarm causes the equipment to immediately switch-off.
After time set on Pr11 (alarms delay) alarm state is reached; press key 4 to reset it.
