klover DIVA - Operative Mode; Stove ignition

8
3. OPERATIVE MODE
The stove's normal functioning principle with reference to the available functions for the user is
described below.
The display appears as in figure 6 before igniting the stove.
SET
OK
Set
°C
1
2 3 4 6
5
22:35
Off
3.1 Stove ignition
Press key 4 for a few seconds to ignite the stove. Ignition is shown on display as in figure 7.
SET
OK
Set
°C
1
2 3 4 6
5
Asp
Fun
The stove sequentially runs the start-up phases as defined by the parameters managing levels and
timing (see “Parameters tables”), after stove ignition.
The method according to which the stove reaches work condition is shown in the following
prospectus, if alarm or anomaly conditions do not arise.
The various functioning conditions, which cleaning, economy modulation, etc. are also described.
Fig. 6
CLOCK
STOVE STATE
Fig. 7
DIALOGUE
