DIVA MID FIRMWARE (DVP070513_6.ENC) GENERAL PARAMETERS ACCESS KEY A9
Parameter
Description
Measurement
Value field
Database P0
Pr01
Ignition cycle maximum time “LOAD PELL”
Minutes
1 – 18
18
Pr02
Start time “FIRE ON”
Minutes
1 – 15
2
Pr03
Time interval between the two brazier cleaning operations
Minutes
2 – 255
60
Pr04
Screw feed motor reducer ON time in ignition phase “LOAD PELL”
Seconds
0.1 – 7.6
1,6
Pr05
Screw feed motor reducer ON time in start phase “FIRE ON”
Seconds
0.1 – 7.6
2,0
Pr06
Screw feed motor reducer ON time in power 1 work phase
Seconds
0.1 – 7.2
1,6
Pr07
Screw feed motor reducer ON time in power 2 work phase
Seconds
0.1 – 7.4
2,6
Pr08
Screw feed motor reducer ON time in power 3 work phase
Seconds
0.1 – 7.6
3,8
Pr09
Screw feed motor reducer ON time in power 4 work phase
Seconds
0.1 – 7.8
5,0
Pr10
Screw feed motor reducer ON time in power 5 work phase
Seconds
0.1 – 8.0
6,2
Pr11
Alarm delay
Seconds
20 – 90
30
Pr12
Temperature differential on “SET H2O” for switch-off/on
°C
2 – 20
10
Pr13
Flue gas minimum temperature to consider equipment on
°C
40 – 120
43
Pr14
Flue gas maximum temperature accepted “ECO FUMI”
°C
130 – 269
260
Pr15
Pump activation threshold
°C
40 – 80
50
Pr16
Flue gas intake device speed during ignition phase “LOAD PELL”
-
0 – 35
14
Pr17
Flue gas intake device speed during start phase “FIRE ON”
-
0 – 35
14
Pr18
Flue gas intake speed in power 1 work phase
-
0 – 35
6
Pr19
Flue gas intake speed in power 2 work phase
-
0 – 35
9
Pr20
Flue gas intake speed in power 3 work phase
-
0 – 35
12
Pr21
Flue gas intake speed in power 4 work phase
-
0 – 35
15
Pr22
Flue gas intake speed in power 5 work phase
-
0 – 35
18
Pr23
Time after which equipment switches off if it remains in “ECO H2O”
Minutes
0 – 240
120
Pr24
Brazier cleaning duration
Seconds
0 – 120
50
Pr25
Differential on “SET H2O” to change-over three-way motorised valve
°C
2 – 30
10
Pr26
Differential on “SET SANI” to change-over three-way motorised valve
°C
2 – 30
5
Pr27
Three-way motorised valve change-over delay
Seconds
2 – 255
60
Pr28
Flue gas intake device switch-off threshold (in stand-by switch-off phase)
°C
40 – 120
80
DIVA MID FIRMWARE (DVP070513_6.ENC) PRE-LOAD PARAMETERS ACCESS KEY B9
Parameter
Description
Measurement
Value field
Database P0
Pr45
Screw feed motor reducer ON time in pre-load phase
Seconds
2 – 255
50
Pr46
Stand-by time after pre-load phase
Seconds
2 – 255
180
Pr47
Flue gas intake device speed in pre-load phase
-
1 – 35
20
DIVA MID FIRMWARE (DVP070513_6.ENC) VENTILATION PARAMETERS ACCESS KEY C9
Parameter
Description
Measurement
Value field
Database P0
Pr67
Flue gas temperature for ventilation switch-on
°C
50 – 120
75
Pr68
Fan speed at ventilation power 1
-
1 – 33
14
Pr69
Fan speed at ventilation power 2
-
1 – 33
33
Pr70
PARAMETER NOT USED
-
-
-
Pr71
PARAMETER NOT USED
-
-
-
Pr72
PARAMETER NOT USED
-
-
-
