BI-FIRE FIRMWARE (BF131211_6.ENC) GENERAL PARAMETERS ACCESS KEY A9
Parameter
Description
Measurement
Value field
Database o0
Pr01
Ignition cycle maximum time “LOAD PELL”
Minutes
1 – 18
18
Pr02
Start time “FIRE ON”
Minutes
1 – 15
5
Pr03
Time interval between the two brazier cleaning operations
Minutes
2 – 240
90
Pr04
Screw feed motor reducer ON time in ignition phase “LOAD PELL”
Seconds
0.1 – 7.6
2,8
Pr05
Screw feed motor reducer ON time in start phase “FIRE ON”
Seconds
0.1 – 7.6
2,4
Pr06
Screw feed motor reducer ON time in power 1 work phase
Seconds
0.1 – 7.2
2,4
Pr07
Screw feed motor reducer ON time in power 2 work phase
Seconds
0.1 – 7.4
3,5
Pr08
Screw feed motor reducer ON time in power 3 work phase
Seconds
0.1 – 7.6
5,0
Pr09
Screw feed motor reducer ON time in power 4 work phase
Seconds
0.1 – 7.8
6,5
Pr10
Screw feed motor reducer ON time in power 5 work phase
Seconds
0.1 – 8.0
7,5
Pr11
Temperature below which the pellet side switches on (on “PELL ON”)
°C
40 – 75
60
Pr12
Temperature differential on “SET H2O” for switch-off/on
°C
1 – 25
10
Pr13
Flue gas minimum temperature to consider equipment on
°C
40 – 120
56
Pr14
Flue gas maximum temperature accepted “ECO FUMI”
°C
130 – 270
260
Pr15
Pump activation threshold
°C
48 – 80
55
Pr16
Flue gas intake device speed during ignition phase “LOAD PELL”
-
0 – 35
30
Pr17
Flue gas intake device speed during start phase “FIRE ON”
-
0 – 35
26
Pr18
Flue gas intake speed in power 1 work phase
-
0 – 35
10
Pr19
Flue gas intake speed in power 2 work phase
-
0 – 35
14
Pr20
Flue gas intake speed in power 3 work phase
-
0 – 35
20
Pr21
Flue gas intake speed in power 4 work phase
-
0 – 35
25
Pr22
Flue gas intake speed in power 5 work phase
-
0 – 35
32
Pr23
Time after which equipment switches off if it remains in “ECO H2O”
Minutes
0 – 120
120
Pr24
Brazier cleaning duration
Seconds
0 – 120
50
Pr25
Differential on “SET H2O” to change-over three-way motorised valve
°C
2 – 30
10
Pr26
Differential on “SET SANI” to change-over three-way motorised valve
°C
2 – 30
5
Pr27
Three-way motorised valve change-over delay
Seconds
2 – 255
60
Pr28
Flue gas intake device switch-off threshold (in stand-by switch-off phase)
°C
40 – 120
80
BI-FIRE FIRMWARE (BF131211_6.ENC) PRE-LOAD PARAMETERS + ADDITIONAL PARAMETERS ACCESS KEY B9
Parameter
Description
Measurement
Value field
Database o0
Pr45
Screw feed motor reducer ON time in pre-load phase
Seconds
2 – 255
2
Pr46
Stand-by time after pre-load phase
Seconds
2 – 255
2
Pr47
Flue gas intake device speed in pre-load phase
-
1 – 35
35
Pr48
Wood flue gas minimum temperature to consider the wood side on
°C
80 – 509
150
Pr49
Recirculation pump activation threshold
°C
31 – 80
50
BI-FIRE FIRMWARE (BF131211_6.ENC) ADDITIONAL PARAMETERS ACCESS KEY C9
Parameter
Description
Measurement
Value field
Database o0
Pr55
Time for pellet side switch-on if the conditions exist after wood side switch-off
Minutes
1 – 50
1
