KMS MP25(M)/MA25(M) manual Version 4.2
62
Minimum system requirements:
Minimum system requirements
Windows XP, Vista, 7, 8, 8.1, 10 or 11
Internal memory 32Mb
Screen resolution 1024x768
Standard USB port
Acrobat reader 3.0 or higher
ECU specifications:
Supply voltage 8.5 - 16V
Power consumption 200mA at 12 V
5V supply to sensors can have maximally 100mA
Inputs:
Inputs are protected up to 50V.
Input for coolant and air temperature is suitable for an NTC-sensor as standard.
(2.2kΩ at 25° Celsius)
Input for engine load is suitable for potentiometers, air mass meters and map sensors with an
output between 0 and 5V.
Outputs:
Injector output can deliver at most 7A at 12V (for instance 6 injectors with a resistance of 16Ω)
Shift-lamp, AUX, cooling fan and fuel pump outputs: max. 1A at 12V per output
Dimensions:
MP25(M) & MA25(M)
LxWxH: 130 x 90 x 45 mm
Weight: 220 gram
