KMS MP25 - Wiring Diagram

KMS MP25(M)/MA25(M) manual Version 4.2 63
8 Wiring diagram
standard colours KMS management MP25(M) / MA25(M) wiring loom
Pin nr. KMS
Colour
Length
Diameter: 0,5mm²
Diameter: 0,75mm²
Function
1
white
*
Lambda signal 1
2
pink/black
*
Oil pressure signal
3
grey/blue
*
Water temperature signal
4
white/red
*
Analog aux input: aux / A.L.S. / launch / lambda signal 2 / EGT
5
red/blue
*
Air temperature signal
6
orange/black
*
Boost Control
7
red/black
*
Tacho output
8
purple
*
Ignition output 3
9
green
*
Ignition output 2
10
orange
*
Ignition output 1
11
white
*
Injector output
12
red
*
12V Injector supply
13
red
*
12V ECU supply
14
yellow
*
5V TPS sensor supply
14
yellow
*
5V MAP sensor supply
15
grey
*
TPS signal
16
grey/black
*
MAP signal
17
black
*
Sensor ground (Air T)
17
black
*
Sensor ground (Water T)
17
black
*
Sensor ground (TPS)
17
black
*
Sensor ground (MAP)
17
blue + shield
* (shielded)
Crank-sensor ground
18
red
* (shielded)
Crank-sensor signal inductive
19
yellow/black
*
Launch Control
20
green/red
*
Powershift / Airco
21
white/black
*
Fuel pump relay
22
yellow/red
*
Aux 3 out
23
blue
*
Aux 1 out / Ignition output 5
24
pink
*
Aux 2 out / Ignition output 4
25
black
*
ECU ground
25
black
*
Lambda ground
