SECTION 12
PARTS LISTS
Jan 2003
page 12-8
80073505
Figure 12-3. SEALING HEAD ASSEMBLY 05144688
ITEM No. QTY PART No. DESCRIPTION
1 1 05144357 Body, Sealing Head
2 1 05144662 Poppet, Inlet, Cutting Water
3 1 05116777 Gland, HP, Sealing Head
4 1 05112768 Seat, HP, Sealing Head
5 1 05116561 Poppet, Valve, HP Check
6 1 05144670 Retainer, Poppet
7 1 05147863 Spring, Compression
8 1 49884562 Spring, Compression
9 1 05116751 Pin, Guide
