SECTION 2
INSTALLATION
Jan 2003
p. 2-2
80074800
• Insure that power is connected prior to equipment turn on.
• Insure that connections have been made for water and pneumatic service.
• Test motor rotation direction and correct if necessary.
• Check and test electrical signal connections between intensifier pump and
cutting area.
• Power up and check out pump (and cutting station, if supplied by KMT
Waterjet) for proper operation.
• Set booster pump discharge pressure.
• Install and test high pressure plumbing.
• Follow the standard test procedure to insure satisfactory performance.
• Train maintenance personnel in the performance of maintenance and repair
procedures.
• Sign off the installation and testing on the KMT Waterjet standard
acceptance document.
2.4 Installation Requirements (Utilities)
Environment:
The SL-IV+ waterjet pump must be installed indoors. Ambient conditions must
not exceed maximum specifications.
Moving:
The SL-IV+ waterjet pump has provisions to be moved with a forklift. Check
weight specifications.
The waterjet pump is top heavy. Avoid situations that
could result in the equipment tipping or overturning.
Electrical connections must be made by qualified
personnel, and must meet national and local electrical
codes.
2.5 Equipment Location/Environment
Space Requirements:
There should be a minimum of 900mm (36 inches) clearance on all sides of the
pump to facilitate service.
Electrical Wiring:
Power supplied to the pump must be in accordance with national and local
electrical codes. See specifications or requirements.
Insure that the service voltage and ampacity are proper for this SL-IV+ pump.
Voltage fluctuations in excess of +/- ten percent of nominal voltage may damage
the SL-IV+ Pump and will void the warranty. Refer to Section 11,
“Specifications”.
1.1.1.2
ARNING
1.1.1.1 CAUTION
