KMT SL-IV PLUS Series User Manual

SECTION 11
SPECIFICATIONS
Jan 2003
p. 11-1
80073455
SECTION 11 SPECIFICATIONS
11 Specifications
Following are the specifications for the Waterjet Pump. Included are the specifications
for the equipment, torque, cutting water, cooling water, and the maximum quantity of
orifices that can be supported.
11.1 Equipment Specifications
SL-IV Waterjet Pump Size
45 (60) kW (hp)
Installation location
Indoors
-Air borne dust/contaminants Minimal
Ambient temperature
-Minimum storage 2(36)
°C(°F)
-Minimum operating 5(40)
°C(°F)
-Maximum operating 40(104)
°C(°F) (see note [1])
Maximum Relative Humidity (see note [2])
-At Maximum Operating Temp. 95%
Electrical (see note [3])
-Motor type TEFC (see note [4])
240/3/60 154 Voltage / Service Amps
480/3/60 77
Volts/Phase/Hertz/Amps
Sound Level 77.16 dB(A)
(Note: Specifications listed below apply equally to 30 hp and 50 hp models)
Controls
-Voltage 24 volts, DC
-Power Supply 10 amps, DC
-Safety shutdown switch settings
High oil temperature 62 (144)
°C (°F)
Low oil level 80 (21) l (gal).
Booster pump overheat 53 (128)
°C (°F)
Hydraulic System
-Oil tank capacity 170 (45) l (gal)
-Recommended oil type
Regular applications
Mobil, DTE Heavy Medium, # 60016-3 (IR #
05022702)
Food applications Conoco AA-20 (IR # 49835762)
-Hydraulic oil operation
Minimum temperature 15(60)
°C(°F)
Maximum temperature 65(150)
°C(°F)
Note [1]: Based on motor nameplate data, oil temperature must be maintained within
operating specifications.
[2]: When relative humidity is above 50%, frequently check oil in tank for water
content.
[3]: Not all motor voltages are readily available, check with factory for availability.
[4]: Totally enclosed fan cooled.
