Knoll Antenna Workspaces - Page 107

Markerboard, Glass, Laminate or Veneer Fence Screens
Assembled Fence Screen
Exploded Hard Surface Fence Screen Assembly
Steps 4 & 6
Step 7
¼-20 Serrated Flange
Hex Nut (B)
¼-20 x 1 ¼" Hex Head
Machine Screw (A)
Screen Panel
Section View of Hard Surface Fence Screen
Screen Panel
¼-20 Serrated Flange Hex Nut (B)
¼-20 x 1 ¼" Hex Head Machine Screw (A)
Aluminum Extrusion
Step 3
1
/
8
" x 1" Roll Pin (C)
1
/
8
" x 1" Roll Pin (C)
