Knoll Antenna Workspaces - Page 116

Desk Supported by 22 ½" High Template Storage
Exploded Desk End Leg Assembly Detail
Step 2
Step 1
Exploded Desk Support
Adapter Assembly Detail
Inset rail end
by 1 ½"
22 ½" High Storage
¼-20 x
5
/
8
"
Machine Screw (H)
Cradle Clamp
Bracket (B)
Horizontal
Rail
Cradle (A)
Step 4
¼-14 x
7
/
8
" Wood
Screw (J)
Step 3
5
/
16
-18 x ¾"
Machine
Screw (I)
Step 5
¼-20 x
5
/
8
"
Machine
Screw (H)
Step 7
Spacer (C) and
#12 X ¾" Black
Wood Screw (F)
Step 6
#14 x 1" FH
Wood Screw (K)
¼-20 x 1" Machine
Screw (G)
Desk to Credenza
Adapter Block (E)
Desk to
Pedestal
Cradle (D)
Cradle Clamp
Bracket (B)
Desk to pedestal
cradle assembly
Desk end leg
assembly
