Knoll Antenna Workspaces - Page 118

ANTENNA 5 V
ANTENNA 5 Y
Desk Supported by 25" High Storage
ANTENNA 5 W
End Cap
Rail
Cradle Clamp Bracket (B)
Desk to Pedestal Cradle (D)
Desk Top
¼-20 x
5
/
8
" Machine Screw (G)
¼-20 x
5
/
8
" Machine Screw (G)
Step 3
Install (1) #10-32 x ¾" self
tapping screw (H) for metal
pedestals OR Install (2)
¼-14 x
7
/
8
" pan head black
wood screws for wood
storage or Template top.
¼-20 x 1"
Machine
Screw (F)
Step 2
Step 2
Step 1
Step 4
Step 5
#14 x 1" FH Wood Screw (I)
Desk Supported by 25" High Storage Plan Detail
Exploded Desk Support Adapter Assembly Detail
Exploded Desk End Leg Assembly Detail
