Knoll Antenna Workspaces - Page 127

Big Table with 25"H Template End Support
big table template brackets
22"h - ybatb22
25"h - ybatb25
bracket detail
bracket detail
Big Table with 25" High
Template End Support
Exploded Support Adapter Assembly for
Big Table - 25"H case, YBATBT25
big table template brackets
22"h - ybatb22
25"h - ybatb25
bracket detail
bracket detail
YBATBT25
Step 3
¼-20 x
5
/
8
" Machine Screw (E)
Cradle Clamp Bracket (B)
Step 1
¼-14 x
7
/
8
" Wood
Screw (D)
Desk to Pedestal
Cradle (C)
Step 10
#14 x 1" FH
Wood Screw (F)
Step 9
#14 x 1" FH Wood
Screw (F)
Step 6
Center Beam
Step 8
Center Beam to Template
Mounting Bracket (A
Drill Template (G)
Template Cabinet
