Knoll Antenna Workspaces - Page 32

Big Table with Inset Intermediate Leg
Inset Intermediate Leg Detail
Center Beam
Horizontal Rail Cradle (A)
Inset Cradle Adapter Assembly
(see exploded view)
Horizontal Rail Cradle AND Inset Cradle Adapter
Assembly (exploded view) Steps 6, 7, & 8
Horizontal Rail Cradle (A)
Inset Intermediate Leg for Big Table
¼-20 x 1" Machine Screw (K)
Cradle Clamp Bracket (B)
Horizontal Rail
Inset Intermediate
Leg Cradle (H)
Inset Cradle Adapter for
Intermediate Leg (G)
¼-20 x
5
/
8
" Machine Screw (L)
Rail
5
/
16
- 18 x 1" Machine
Screw (O)
#14 x 1" FH Wood Screw (M)
