Knoll Antenna Workspaces - Page 36

Big Table with Intermediate Leg (Non-Inset)
Big Table with Intermediate Leg (Non-Inset) Assembly
Step 1
Step 14
Step 12
Step 13
Step 3
Steps 8 & 9
Center Beam
Step 8
Step 7
Starter rails and extended rails
meet in the center of the cradle
Intermediate Leg Detail (non-inset)
Center
Beam
Horizontal Rail
Cradle (A)
Center Beam
Mounting
Bracket (E)
NOTE: (2) Flat brackets
(not shown) must be
used to connect adjacent
tops (see step 11)
Top
Bottom
Side
Center Beam Orientation
