Partially Exploded End Leg for Back-to-Back Returns
Back-to-Back Return Attachment Exploded Detail
Return Rail Hook Top Bracket (E)
Return Rail Clamp Bottom Bracket (F)
W-Bracket (G)
Big Table Desk Rail
Flat Bracket (Under
Big Table Seam)
Intermediate Leg
Steps 5 & 6
Steps 8 & 11
#14 x 1" FH wood screw (J)
¼-20 x 1" machine screw (H)
Return Rails
Big Table with Back-to-Back Returns
