Knoll Antenna Workspaces - Wire Basket Covers and End Caps

Cable Management: Wire Basket Cover (pair)
and End Cap (pair)
STEPS:
NOTE: Before assembly, verify the correct
installation of mounted cable baskets. Cable
baskets must be the same depth, with a
4" or 7" downmount bracket (YR1CBB4
or YR1CBB7), and have a 1-
3
/
8
" spacing
bracket (YR1CBH) between the baskets.
Install Slide Covers:
1. Remove backing paper and position
(2) Foam Tape squares (A) on each
side cover, directly inboard of the lower
tabs (see the diagram below).
2. Hook a side cover on top of the mounted
cable basket assembly, centered over
the cable basket. Rotate the side cover
downwards into a vertical position and engage
the bottom snaps on the underside of the
basket. Repeat for the opposite side cover.
Install End Covers:
3. Engage the bottom tabs of an End Cap into
the ends of the Side Covers. Rotate the end
cap upwards into a vertical position and
engage the upper tabs into the tops of the side
covers. Repeat for the opposite end cap.
(A) 3AB4467
Pattern Numbers Represented:
Wire Basket Cover (pair), YR1CBC_
Wire Basket End Cap,6" YR1CBE06
Wire Basket End Cap, 12", YR1CBE12
Parts List:
Side Cover
End Cap
Foam Tape (A)
Pre-Assembled Antenna Table, Desk, or Big Table
with Upper and Lower Cable Baskets Installed
Tools Needed:
None
