Knoll Antenna Workspaces - Page 77

Desk Supported by 25"H or 28 ½"H Fence
Exploded Desk Rail Connection to Fence Detail (25"H Fence Shown)
¼-20 x
5
/
8
" Machine Screw (I)
Cradle Clamp Bracket (E)
Fence End Support Cradle:
(B) for 25"H Fence; (C) for 28½"H Fence
Step 16
#14 x 1" FH wood screw (J)
Steps 7 & 8
Fence to Plate Weldments (A)
Step 7
#14 x 1" FH Wood Screw (J)
Step 10
1
1
/
8
" Rail Extensions (K)
Step 11
Starter Rail
Step 9
End Cap
Step 12
Desk Supported by Fence Plan View
Fence End Support Cradle/Rail Attachment
Detail (25"H Fence Shown)
End Cap
1
1
/
8
" Rail Extension (K)
Starter Rail
