Knoll Antenna Workspaces - Page 88

Big Table Screens
Bayonet Mount Bracket Assembly Detail
Spring Nut (A)
Bayonet Mount Bracket (C)
Step 1
Step 2
Screen
M6 x 25 mm
Machine Screw (B)
Partially Exploded Big Table Screen Assembly
Center Beam
Bayonet Mount
Bracket Assembly
Screen
