2-6 November 2014
Setting Up the Printer
8. Remove the plastic wrapper from the new ribbon. Do not
remove the paper band.
9. Load the new ribbon into the cassette:
a. Insert the supply spool in the cassette on the side with the
yellow label. Make sure that the flange on the spool is seated
on the outside of the cassette.
b. Snap the spool into place.
10. Tear the paper band from the ribbon.
11. Remove the paper band from the ribbon.
To Next Page
