Setting Up the Printer
November 2014 2-5
Loading the Ribbon
Make sure you have the KODAK D4600S Duplex Photo Ribbon or
KODAK D4600L Duplex Photo Ribbon available (see “Printer
Supplies” on page 1-3).
1. Move the power switch to the On ( | ) position.
2. Open the front of the printer.
• Press the release button.
• Pull the front of the printer forward until it stops.
3. Open the top door of the printer.
4. Are you loading the ribbon for the first time?
5. Pull up on the handle to remove the ribbon cassette. Support
the cassette with two hands.
6. Place the cassette on a flat surface.
7. Remove the used ribbon from the cassette. Dispose of the used
ribbon appropriately.
IMPORTANT: Images remain on the ribbon after printing. Maintain
confidentiality.
Ye s N o
Go to step 9. Continue with step 5.
