www.kodak.com/go/aiosupport 27
KODAK ESP 7 All-in-One Printer
Setting up an IP address
If you have discovered that you are connected to the access point but you are not
connected to the network, you may need to set up your IP address on the printer.
1. From the Network Settings menu, select
Manual IP Address and press OK.
2. Select one of the options displayed:
•
Dynamic (DHCP)
•
Automatic (Private)
• Manual (Static)
3. Then press OK to continue.
4. Depending on the IP address type specified, you may be prompted to enter an IP
address, a Subnet Mask, a Gateway Address; and a DNS Server address. Press
OK after making each entry. See your network provider for more information.
All address entries are made in the following format: 000.000.000.000. Any
address or subnet mask that has only 2 characters between stops shall have a
leading zero entered in front of that number. For example:
To obtain the IP Address on a Windows operating system:
You must use a computer on your network.
a. Select
Start > Run.
b. Type
cmd.
c. Type
ipconfig and then press Enter. If configured, IP Address, Subnet Mask and
Gateway Address (Default Gateway) are shown.
Tip: Your Gateway Address is usually the router address.
To obtain the IP Address on a Macintosh operating system:
You must use a computer on your network.
a. Open
System Preferences.
b. Under
Internet and Network, click Network. Select the Wireless Network. Your IP
address will be shown.
Verifying network configuration
You can verify that you are connected to a network from your printer menu.
1. Press until
Network Settings is selected, and then press OK.
2. Press until
View Network Configuration is selected, and then press OK. When
you select this menu item, the printer displays the configuration settings for
both Ethernet and Wi-Fi networks on the LCD screen.
Address or Subnet
Mask Format
Printer Entry Format
149.89.138.149 149.
089.138.149
149.2.40.149 149.
002.040.149
