1 Printer Overview
This printer lets you print, copy, scan, and fax pictures and documents. In addition,
this printer supports networking, letting you access the printer over a wireless
(Wi-Fi) or Ethernet network.
Components
1 Control panel 11 Access door
2 Automatic Document Feeder (ADF) 12 Printhead with ink cartridges installed
3 ADF paper-edge guides 13 Front USB port
4 Line in phone port 14 Memory card slot
5 Ext out phone port 15 Paper tray
6 USB port (for connecting to computer) 16 Scanner glass
7 Power cord port 17 Scanner lid
8 Ethernet port 18 Output tray extender with paper stop
9 Rear-access cleanout area 19 Output tray
10 Duplexer (pulled out)
