C37XGPW Board (Power source board)
CASM5 Board (Main board)
Remove the 6 M3 button screws on the top of the control panel, grab the power button and lift it
up, and the control panel will pop up.
(If you open the maintenance slid and press from the back, it will easily pop up.)
The CASM5 board (main board) is installed on the back side of the control panel.
Caution: Don’t remove each boards unnecessarily. When performing maintenance such as internal
cleanup, be careful not to drop or loosen the board connectors.
Caution: When returning the control panel, be careful not to contact the harness on the back of the
control panel with the mechanical parts.
