KODERA CASTING C370G - Specifications

36
Specifications
April 4, 2024㋔
※ For improvement, these specifications are subject to be changed without notice.
Model
CASTING C370G
Outer Dimensions
W:450mm×D:450mm×H:270mm
Weight
26kg
Power Source
AC100V ～ AC240V (Single Phase) ±10％ 50Hz/60Hz
Power Consumption
25Wh（rating） 122Wh（max.）
Cutting length
0.1mm ～99999mm
Cutting Tolerance
Less than ±(0.1 + 0.0005×L)mm L＝Cutting length
(Depending of the wire)
Strip Length
Settable
Front end 0.1mm ～ 30mm
Rear end 0.1mm ～ 30mm
Process-
able
Wire
Type
AVSS, VSF, IV, KIV, KV, UL, Teflon、Glass wire etc.
Size
AWG#10（5.5sq）～#32（0.03sq）
（Depending on the wire）
Outer
Size
Maximum φ6mm （Depending on the wire）
Wire Feeding Speed
Variable
Material of Blade
Ultra micro-particulate mixed metal
Motive Power
Stepping Motor
