Specifications
Aug 30 2021 F
※These specifications are subject to be changed without notice for the sake of improvement.
Model
C371A
Outer Dimensions
W:430mm × D:420mm × H:270mm
Weight
27 kg
Power Source
AC 100 V ~ 240 V ±10% 50Hz/60Hz
Power Consumption
50 W(rating) 300 W(max.) At AC100V
Cutting length
0.1mm ~ 99999mm
Cutting Tolerance
Less than ±(0.1 + 0.0005 ×L)mm L=Cutting length
(Depending of the wire)
Strip Length
Settable
Front end 0.1 mm ~47.9 mm
Rear end 0.1 mm ~47.9 mm
Process-
able
Wire
Type
AVSS, VSF, IV, KV, UL, Teflon、Glass wire etc.
Size
AWG#7 (10 sq)~#28 (0.08 sq)
(Depending on the wire)
Outer
Size
Maximum φ11 mm
Wire Feeding Speed
Variable
Material of Blade
Ultra micro-particulate mixed metal
Drive supply
Stepping motor
