11.3
Section 11
Emission Compliance Systems
11
1. Remove the inlet screen from the secondary air valve assembly by grasping the inlet screen at the base and
gently pulling away from the valve assembly. See Figure 11-3.
Secondary Air Valve
Assembly
Inlet Screen
Figure 11-3. Remove Inlet Screen.
2. Use a so brush to remove debris from the screen.
3. Run water through the inlet screen in the reverse direction.
4. To reinstall, push the inlet screen onto the barb of the secondary air valve assembly. See Figure 11-3. An
audible click will be heard when the inlet screen is properly reinstalled.
Barb
