Stacked Jumpers:
• Under normal operation all machines will have a jumper across the left pins. If this jumper is
removed the water valve will stay energized to thoroughly rinse the water plate during the
water plate lowering, harvest and water plate rising cycles.
Note: The machine will need reset for the controller to acknowledge this change.
• The right jumper is used to tell the controller when it is being used on a dual evaporator
machine (GB1064 models only). This is set at the factory and should never be removed.
Programming Port: Used by service technicians to alter or update the controllers software.
Water Level Sensor: Port for water level sensor probes.
Evaporator Temperature Adjustment: To increase the temperature of the evaporator at which
the water plate closes, turn this dial counterclockwise. To decrease, turn the dial clockwise. The
operator can adjust the harvest termination temperature between 35 and 60F.
Note: After adjustment the controller must be reset.
Reset Button: Reboots the controller.
Temperature Sensor Port: For evaporator and bin temperature sensor probes.
